Land Rover Discovery 1995 Chassis Repair Methods Manual PDF

This 20-page digital chassis repair methods manual covers the 1995 Land Rover Discovery, with the repair methods and time information developed using a Discovery TDi research vehicle. It is a specialist chassis-focused manual containing illustrated procedures for front, side and rear chassis repairs, including crossmembers, body mounts, outriggers, trailing link brackets and chassis section replacement.

The manual also covers chassis welding methods, alignment and dimensional checking, corrosion protection, refinishing, M.E.T. requirements and replacement-time information. It is particularly useful for professional body repairers, chassis specialists, restorers and owners undertaking structural repairs on 1995 Discovery models.

What's Included

• 20-page illustrated digital PDF

• Chassis repair methods and technical diagrams

• Front, side and rear chassis repair operations

• M.E.T. requirements associated with chassis repairs

• Repair and replacement time schedules

Chassis Repair Operations

Detailed illustrated repair information includes:

• Front crossmember and corner gusset replacement

• Chassis section replacement

• Front, centre and rear body mount repairs

• Bolted crossmember replacement

• Front outrigger and C-spanner bracket replacement

• Rear trailing link bracket replacement

• Rear outrigger replacement

• Rear crossmember replacement

Welding, Alignment & Dimensions

The manual contains chassis welding guidance together with illustrated weld locations. Chassis alignment information includes a special alignment jig drawing and a basic chassis dimensions check with identified measuring points.

Corrosion Protection & Refinishing

Includes post-repair corrosion protection procedures, illustrated chassis cavity treatment locations and chassis paint/refinishing information.

Repair & Labour Time Information

Replacement-time schedules are provided for a range of chassis, M.E.T., paint and corrosion-protection operations. The actual technical time values are contained within the manual.

Vehicle Coverage

Land Rover Discovery — 1995.

The repair methods and times were established using a Discovery TDi. The manual notes that variations from this specification may require adjustment.

Useful For

• Professional body and accident repairers

• Land Rover restoration specialists

• Chassis repair and fabrication workshops

• Discovery owners undertaking structural restoration

• Assessing chassis repair operations and associated work

DIGITAL PDF DOWNLOAD — NO PHYSICAL BOOK WILL BE POSTED

Supplied as a 20-page PDF digital download.
